Interfaccia audio USB per PC/MAC e iPad (via Camera Kit o Lightning-to-USB non inclusi)
– 4 ingressi simultanei
– Due ingressi combo XLR/Jack con preamp di prima qualità e alimentazione Phantom a 48v – Input 1 con ingresso Hi-Z
– Risoluzione fino a 24-bit/96 kHz
– Zero-latency direct monitoring
– Slot a 10 pin per capsule microfoniche
– Utilizzabile stand alone senza collegamento con il computer
– Connessioni MIDI, S/PDIF ottico o coassiale
– Uscita cuffie
– Uscita RCA
– Codice di download per Ableton Live 9 Lite
– Alimentabile con trasformatore o a batterie (4 ore di autonomia)
– Driver e firmware: http://tinyurl.com/hdujnvo
SPECS
ANALOG IN: INPUT 1/2
CONNECTOR: | TRS/XLR combo jacks (XLR: 2 hot, TRS: TIP hot) |
INPUT GAIN: | 0 – 43 dB |
INPUT IMPEDANCE: | 2.6 k Ω (MIC IN) 1.1 M Ω (when Hi-Z ON) |
MAXIMUM INPUT LEVEL: | +2.7 dBu (MIC IN) /+20.7 dBu (TRS IN) |
PHANTOM POWER: | +48V |
ANALOG IN: MIC IN
SUPPORTED ZOOM INPUT CAPSULES: | XYH-6, MSH-6, SGH-6, EXH-6, SSH-6, XYH-5 |
ANALOG OUT: MAIN OUT L/R
CONNECTOR: | TRS phone jacks (unbalanced) |
MAXIMUM OUTPUT LEVEL: | +10 dBu (at 0 dBFS) |
OUTPUT IMPEDANCE: | 330 Ω |
ANALOG OUT: LINE OUT 1/2
CONNECTOR: | RCA (coaxial) |
MAXIMUM OUTPUT LEVEL: | +8 dBu (at 0 dBFS) |
OUTPUT IMPEDANCE: | 1kΩ |
ANALOG OUT: PHONES
CONNECTOR: | Standard stereo phone jack 30 mW x 2 (into 32 Ω load) |
MAXIMUM OUTPUT LEVEL: | +10 dBu (at 0 dBFS) |
OUTPUT IMPEDANCE: | 33 Ω |
DIGITAL IN/OUT: S/PDIF OPTICAL
CONNECTOR: | TOSLINK |
SUPPORTED SAMPLING FREQUENCIES: | 96 kHz, 88.2 kHz, 48 kHz, 44.1 kHz |
DIGITAL IN/OUT: S/PDIF COAXIAL
CONNECTOR: | RCA (coaxial) |
SUPPORTED SAMPLING FREQUENCIES: | 96 kHz, 88.2 kHz, 48 kHz, 44.1 kHz |
Additional Specifications
FREQUENCY CHARACTERISTICS: | At 44.1 kHz: ±1.5 dB: 20 Hz – 20 kHz At 96 kHz: ±2 dB: 20 Hz – 40 kHz |
INPUT CONVERSION NOISE: | Measured EIN: -119.5 dB (IHF-A) at 43 dB, 150 Ω input |
NUMBER OF AUDIO RECORDING AND PLAYBACK CHANNELS: | Recording: 4 channels Playback: 4 channels |
SAMPLING FREQUENCIES: | 96 kHz, 88.2 kHz, 48 kHz, 44.1 kHz |
BIT DEPTH: | 24-bit |
INTERFACE: | USB 2.0 |
MIDI IN/OUT: | 5-pin DIN jack |
POWER SOURCE: | USB bus power (Type B) ZOOM AD-17 (Micro-B) DC 5V power supply (Micro-B) 2 AA batteries (4 hours continuous operation with phantom power off) |
POWER CONSUMPTION: | 5W maximum |
DIMENSIONS: | 198.8 mm (D) 92.3 mm (W) 42.7 mm (H) |
WEIGHT (MAIN UNIT ONLY): | 310 g |
U-44 SYSTEM REQUIREMENTS
WINDOWS: | OS: Windows® 8.1 ~ 11 (32bit/64bit) CPU: Intel® Core i3 or faster* USB: USB 3.0/USB 2.0*** Operation is not guaranteed with CPUs from Atom, Celeron or Pentium series or CPUs made by AMD. ** Only USB host controllers with Intel Chipsets are supported. Operation is not guaranteed when used with USB hubs or expansion cards. | |
MAC:: | OS: Mac® OS X 10.9.5 ~ 12 CPU: Intel® Core i3 or faster USB: USB 3.0/USB 2.0** Operation is not guaranteed when used with USB hubs or expansion cards. | |
IPHONE/IPAD | OS: iOS 7.1 ~ 15 * Requires 2 AA batteries or optional AC adapter for power, plus an Apple iPad Camera Connection Kit or Lightning-to-USB Camera Adapter. |
